| Brand Name : | OEM / LinkAV |
| Model Number : | LKAV3618 |
| Certification : | CE，FCC |
| Price : | USD, RMB |
| Payment Terms : | T/T, PayPal, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability : | 1000pcs/Month |
| Delivery Time : | Negotiable |
The LKAV3618 is an airborne Mesh radio that utilizes an FPGA solution. It supports adaptive frequency hopping and selection, automatically choosing the optimal frequency in the presence of electromagnetic interference. This enables broadband network self-organization and transmission in complex scenarios. It can be used in various communication combinations for different usage scenarios, such as on moving UAVs or USVs, allowing for easy plug-and-play operation without the need for configuration or parameter changes. It is primarily used for multimedia interconnection between drones and base stations, as well as serving as a Mesh rela
* Data rate up to 56Mbps
* Full transparent IP data transmission
* With HDMI input
* Supports GPS/BD
* Supports up to 10nodes(Customizable)
* With TTL and LAN interface
| RF Parameters | |
| Default Frequencies | 1300-1500MHz (70MHz-6GHz customizable) |
| Channel Bandwidth | 2.5M/5M/10M/20MHz (40MHz optional) |
| RF Waveform | TDD-COFDM (2T2R) |
| Output Power | 2x2W, 1dBm step adjustable |
| Receive Sensitivity | -100dBm@2.5MHz |
| Modulation Type | BPSK/QPSK/16QAM/64QAM (adaptive) |
| FHSS | Optional (>1000 hop/s) |
| IFS | Optional |
| Network Parameters | |
| Network Size | Up to 10nodes(Customizable) |
| Multi-hop Capability | 15 hops (short message); 10 hops (voice); 8 hops (video) |
| Range | 30-49km (Ground-to-Ground LOS) |
| Data rate | Up to 28Mbps@10MHz & 56Mbps@20MHz |
| Delay | 7ms@2.5MHz/hop |
| Movement Speed | >1000km/h |
| Start Time | 27s |
| Positioning | GPS/BD/GLONASS (GNSS) |
| Network Access Time | <1s |
| Network Extension | WIFI AP |
| Electrical Parameters | |
| Working Voltage | 12-36V DC |
| Power Consumption | ≤237dBm |
| Physical/Environment | |
| Weight | 475g |
| Dimensions | 120*90*40mm |
| Working Temp. | -40°C~70°C |
| Interface | |
| LAN Interface | *1 |
| Serial Interface | RS232*1 (Or TTL) |
| Video Interface | Mini HDMI*1 |
Linkav technology Co.,Ltd has multiple patents with independent intellectual property rights, has established a sound quality system and national standard system that comply with ISO9001 standards, and strictly produces products in accordance with national standards and internationally recognized standards such as CCC, CE, FCC, etc. It has obtained the Radio Transmission Equipment Model Approval Certificate issued by the Ministry of Industry and Information Technology of China and has passed the wireless product testing certification of the Ministry of Public Security.
|
|
