Mini Wireless COFDM Transmitter Audio Video Command Center with HDMI video input
Front-end Product model: LKAV-C328
It is ideal for use in body-worn, covert applications or in fixed deployments.
The transmitter provides excellent distance and performance through its range of wireless transmission bandwidths.
Technical Parameters:
Item | Description |
Modulation method | COFDM |
Working Frequency | 45~2.5GHz; per 0.1M adjustable |
Transmission Power | 1W |
RF Bandwidth | 2/3/4/5/6/7/8MHz (adjustable) |
FEC(forward error correction) | 1/2,2/3,3/4,7/8 |
Guard Interval | 1/4,1/8,1/16,1/32 |
Video Input | HDMI: Support 1080P,1080i,720P,720i |
Video Compression | H.264 |
RF Interface | SMA F head |
Parameter Control Method | Adjustable digital LED control panel |
Encryption Method | 256 - bit AES (can set user’s password) |
Transmission Distance | Over 1KM in favorable conditions |
Working Voltage | AC220V |
Working Current | 1.55A |
Working Temperature | -10~70℃ |
Weight | 203g |
Dimensions | 86x65x26(mm) or 120x65x26(mm) with battery |
The front-end transmitting device included: Omni directional whip antenna,mini individual transmitter(the above is standard configuration),hand-held camera,helmet camera,knapsack,standby battery(the above for optional)
Application Scenes:
Can be used for Public security, fire fighting,traffic warden,Civil air defense emergency, City administration, Monitoring of environment, Water conservation, flood prevention, Power and emergency, Railway emergency rescue, Maritime,Coastguard patrol,The customs border,Dock/Quay monitoring, Forest-fire prevention,Oil field, reconnaissance, TV transmit etc.
It is suitable for real-time mobile transmit the high quality image/audio/video in the urban area, seaborne, mountainous region etc complicated environment.
|
|
